Tellus Series

Tellus Series
LED Floor Tile Panel

Intelligent Sensing Interaction

Convenient Installation

Comprehensive Protection

Heavyweight Load Capacity

Intelligent interactive sensing

Equipped with built-in laser sensors and MCU control chips, it possesses high sensitivity and strong anti-interference capabilities. Combined with our independently developed floor interactive sensing system, which allows for a contactless interactive experience.

Convenient installation

Custom metal pedestals allow flexible height adjustments, simplifying the installation process.

High load-bearing capacity

The die-casting cabinet adopts a skeleton-type load-bearing design and pressure-resistant materials, with a load-bearing capacity of 2000-2500kg/m².

Comprehensive protection

Corner anti-collision design
Optional spring lock on the cabinet
Anti-slip and anti-scratch surface
IP54 protection rating

360° all-around design

All spectators can experience outstanding visual effects

COD colloidal permeable membrane pressing technology

The module adopts COD colloidal permeable membrane pressing technology, ensuring high ink colour consistency while effectively protecting the LED beads from temperature variations, friction, and impacts.

Various installation methods

The Tellus series can be used not only as a tile display but also supports curved installation, hanging installation, and floor-standing installation, meeting diverse user installation requirements. It is the perfect choice for XR virtual shooting solutions.

Specifications

Tellus Series LED Floor Tile Panel

BU55-1P5VA

BU55-1P9VA

BU55-2P6VA

BU55-2P6VA(P)

BU55-2P9VA

BU55-3P9VA

BU55-2P9VA(M)

BU55-3P9VA(M)

Model
Pixel Pitch(mm)
Resolution
Cabinet Size(W × H × D)(mm)
IP Rate
Brightness(nits = cd/m²)
Colour Temperature(K)
Frame Rate(Hz)
Refresh Rate(Hz)
Working Voltage
Power Consumption Max(W/m²)
Power Consumption AVG (W/m²)
Viewing Angle(H./V.)
Lifetime(Hours)
Operating Temp(℃)
Humidity Range(%RH)
Cabinet Weight(kg)

BU55-1P5VA
P1.56
320*320
500 x 500 x 82
Front: IP43 Back: IP55
800
3000K~9300K(adjustable)
60
3840
AC: 100V~240V,50/60Hz
540
180
120°/120°
100000
-10 ~ +50
10 ~ 80
11

BU55-1P9VA
P1.95
256*256
500 x 500 x 82
Front: IP43 Back: IP55
800
3000K~9300K(adjustable)
60
3840
AC: 100V~240V,50/60Hz
540
180
120°/120°
100000
-10 ~ +50
10 ~ 80
11

BU55-2P6VA
P2.604
192*192
500 x 500 x 82
Front: IP43 Back: IP55
800
3000K~9300K(adjustable)
60
3840
AC: 100V~240V,50/60Hz
540
180
120°/120°
100000
-10 ~ +50
10 ~ 80
11

BU55-2P6VA(P)
P2.604
192*192
500 x 500 x 82
Front: IP43 Back: IP55
800
3000K~9300K(adjustable)
60
3840
AC: 100V~240V,50/60Hz
540
180
120°/120°
100000
-10 ~ +50
10 ~ 80
11

BU55-2P9VA
P2.97
168*168
500 x 500 x 82
Front: IP43 Back: IP55
800
3000K~9300K(adjustable)
60
3840
AC: 100V~240V,50/60Hz
540
180
120°/120°
100000
-10 ~ +50
10 ~ 80
11

BU55-3P9VA
P3.91
128*128
500 x 500 x 82
Front: IP43 Back: IP55
800
3000K~9300K(adjustable)
60
3840
AC: 100V~240V,50/60Hz
540
180
120°/120°
100000
-10 ~ +50
10 ~ 80
11

BU55-2P9VA(M)
P2.97
168*168
500 x 500 x 82
IP55
2000
3000K~9300K(adjustable)
60
3840
AC: 100V~240V,50/60Hz
540
180
120°/120°
100000
-10 ~ +50
10 ~ 80
11

BU55-3P9VA(M)
P3.91
128*128
500 x 500 x 82
IP55
2500
3000K~9300K(adjustable)
60
3840
AC: 100V~240V,50/60Hz
540
180
120°/120°
100000
-10 ~ +50
10 ~ 80
11
